AOK20B65M1
AlphaIGBT™
Status: Full Production
AlphaIGBT 提供业界领先的快速关断和低 VCE(SAT) 性能，从而实现更大的安全设计空间。可控的接通di/dt可有效降低EMI设计，适用于大多数家用电器、工业和汽车应用。
- 更低的导通损耗
- 更低的开关损耗
- 更低的EMI性能
- 更高的坚固性
Parametrics
Status | Full Production |
Package | TO247 |
Configuration | IGBT with Anti-Parallel Diode |
Qg (nC) | 46 |
Qrr (nC) | 800 |
VF (V) | 1.66 |
VCE max (V) | 650 |
VCE(SAT) typ (V) | 1.70 |
Ic max @ 25C (A) | 40 |
Ic max @ 100C (A) | 20 |
EON (mJ) | 0.47 |
EOFF (mJ) | 0.27 |
IRM (A) | 5.20 |
Status | Full Production |
Package | TO247 |
Configuration | IGBT with Anti-Parallel Diode |
Qg (nC) | 46 |
Qrr (nC) | 160 |
VF (V) | 1.66 |
VCE max (V) | 650 |
VCE(SAT) typ (V) | 1.70 |
Ic max @ 25C (A) | 40 |
Ic max @ 100C (A) | 20 |
EON (mJ) | 0.47 |
EOFF (mJ) | 0.27 |
IRM (A) | 7.10 |
Parametrics
Status | Full Production |
Package | TO247 |
Configuration | IGBT with Anti-Parallel Diode |
Qg (nC) | 46 |
Qrr (nC) | 800 |
VF (V) | 1.66 |
VCE max (V) | 650 |
VCE(SAT) typ (V) | 1.70 |
Ic max @ 25C (A) | 40 |
Ic max @ 100C (A) | 20 |
EON (mJ) | 0.47 |
EOFF (mJ) | 0.27 |
IRM (A) | 5.20 |
Status | Full Production |
Package | TO247 |
Configuration | IGBT with Anti-Parallel Diode |
Qg (nC) | 46 |
Qrr (nC) | 160 |
VF (V) | 1.66 |
VCE max (V) | 650 |
VCE(SAT) typ (V) | 1.70 |
Ic max @ 25C (A) | 40 |
Ic max @ 100C (A) | 20 |
EON (mJ) | 0.47 |
EOFF (mJ) | 0.27 |
IRM (A) | 7.10 |
Documentation
| Title | Type | Date | File |
|---|---|---|---|
| AOK20B65M1 Datasheet | Datasheets | 2016-06-20 | |
| AOK20B65M1 Marking | Markings | 2015-08-03 | |
| AOK20B65M1 Reliability Report | Reliability Reports | 2021-05-20 | |
| TO247 | Package | 2024-09-14 | |
| TO247 Tube | Tube | 2023-10-06 |
