AOTF15S65
High Voltage MOSFETs (500V - 1000V)
Status: Full Production
650V 15A aMOS™ Power Transistor
Parametrics
Status | Full Production |
Package | TO220F |
Configuration | Single |
Polarity | N |
VDS (V) | 650 |
VGS (±V) | 30 |
ID @ 25°C (A) | 15 |
PD @ 25°C (W) | 50 |
RDS(ON) max (mΩ) at VGS= 10V | 290 |
Qg (10V)(nC) | 17.20 |
VGS(th) max (V) | 4 |
Ciss (pF) | 841 |
Coss (pF) | 58 |
Crss (pF) | 1.10 |
Qgd (nC) | 5.30 |
tD(on) (ns) | 27 |
tD(off) (ns) | 90 |
Trr (ns) | 320 |
Qrr (nC) | 5500 |
Qualification | Industrial |
ESD Diode | No |
Tj max (°C) | 150 |
Parametrics
Status | Full Production |
Package | TO220F |
Configuration | Single |
Polarity | N |
VDS (V) | 650 |
VGS (±V) | 30 |
ID @ 25°C (A) | 15 |
PD @ 25°C (W) | 50 |
RDS(ON) max (mΩ) at VGS= 10V | 290 |
Qg (10V)(nC) | 17.20 |
VGS(th) max (V) | 4 |
Ciss (pF) | 841 |
Coss (pF) | 58 |
Crss (pF) | 1.10 |
Qgd (nC) | 5.30 |
tD(on) (ns) | 27 |
tD(off) (ns) | 90 |
Trr (ns) | 320 |
Qrr (nC) | 5500 |
Qualification | Industrial |
ESD Diode | No |
Tj max (°C) | 150 |
Documentation
| Title | Type | Date | File |
|---|---|---|---|
| AOTF15S65 Datasheet | Datasheets | 2024-06-14 | |
| AOTF15S65 Marking | Markings | 2019-02-12 | |
| AOTF15S65 Reliability Report | Reliability Reports | 2021-05-20 | |
| TO220F | Package | 2020-08-11 | |
| TO220F Tape & Reel | Tape & Reel | 2023-07-17 |
Package Details
| Package Name | Dimensions | Package Specifications | Packaging Method |
|---|---|---|---|
| TO220F | 10.16x28.85x4.7 | Tape and Reel |
