AO3400
Low Voltage MOSFETs (12V - 30V)
Status: Obsolete
30V N-Channel MOSFET
Obsolete, please review our suggested replacement AOSS32334C
Parametrics
Status | Obsolete |
Replacement Parts | AOSS32334C |
Package | SOT23 |
Configuration | Single |
Polarity | N |
VDS (V) | 30 |
RDS(ON) max (mΩ) at VGS= 10V | 28 |
RDS(ON) max (mΩ) at VGS= 4.5V | 33 |
RDS(ON) max (mΩ) at VGS= 2.5V | 52 |
VGS (±V) | 12 |
ID @ 25°C (A) | 5.80 |
PD @ 25°C (W) | 1.40 |
Qg (4.5V)(nC) | 6 |
VGS(th) max (V) | 1.45 |
Ciss (pF) | 630 |
Coss (pF) | 75 |
Crss (pF) | 50 |
Qgd (nC) | 1.80 |
tD(on) (ns) | 3 |
tD(off) (ns) | 25 |
Trr (ns) | 8.50 |
Qrr (nC) | 2.60 |
ESD Diode | No |
Tj max (°C) | 150 |
Qualification | Industrial |
Parametrics
Status | Obsolete |
Replacement Parts | AOSS32334C |
Package | SOT23 |
Configuration | Single |
Polarity | N |
VDS (V) | 30 |
RDS(ON) max (mΩ) at VGS= 10V | 28 |
RDS(ON) max (mΩ) at VGS= 4.5V | 33 |
RDS(ON) max (mΩ) at VGS= 2.5V | 52 |
VGS (±V) | 12 |
ID @ 25°C (A) | 5.80 |
PD @ 25°C (W) | 1.40 |
Qg (4.5V)(nC) | 6 |
VGS(th) max (V) | 1.45 |
Ciss (pF) | 630 |
Coss (pF) | 75 |
Crss (pF) | 50 |
Qgd (nC) | 1.80 |
tD(on) (ns) | 3 |
tD(off) (ns) | 25 |
Trr (ns) | 8.50 |
Qrr (nC) | 2.60 |
ESD Diode | No |
Tj max (°C) | 150 |
Qualification | Industrial |
Documentation
| Title | Type | Date | File |
|---|---|---|---|
| AO3400 Datasheet | Datasheets | 2019-02-12 | |
| AO3400 Marking | Markings | 2019-02-12 | |
| AO3400 Reliability Report | Reliability Reports | 2019-02-12 | |
| SOT23 | Package | 2021-06-16 | |
| SOT23 Tape & Reel | Tape & Reel | 2023-10-06 |
Package Details
| Package Name | Dimensions | Package Specifications | Packaging Method |
|---|---|---|---|
| SOT23 | 2.90x2.80 | Tape and Reel |
