AONS36306
Low Voltage MOSFETs (12V - 30V)
Status: Full Production
30V N-Channel MOSFET
Parametrics
Status | Full Production |
Package | DFN5x6-8L |
Configuration | Single |
Polarity | N |
VDS (V) | 30 |
RDS(ON) max (mΩ) at VGS= 10V | 5.20 |
RDS(ON) max (mΩ) at VGS= 4.5V | 8.60 |
VGS (±V) | 20 |
ID @ 25°C (A) | 63 |
PD @ 25°C (W) | 28 |
Qg (4.5V)(nC) | 8 |
Qg (10V)(nC) | 17 |
VGS(th) max (V) | 2.20 |
Ciss (pF) | 1000 |
Coss (pF) | 290 |
Crss (pF) | 50 |
Qgd (nC) | 4.10 |
tD(on) (ns) | 6.50 |
tD(off) (ns) | 19 |
Trr (ns) | 11 |
Qrr (nC) | 19 |
ESD Diode | No |
Tj max (°C) | 150 |
Qualification | Industrial |
Parametrics
Status | Full Production |
Package | DFN5x6-8L |
Configuration | Single |
Polarity | N |
VDS (V) | 30 |
RDS(ON) max (mΩ) at VGS= 10V | 5.20 |
RDS(ON) max (mΩ) at VGS= 4.5V | 8.60 |
VGS (±V) | 20 |
ID @ 25°C (A) | 63 |
PD @ 25°C (W) | 28 |
Qg (4.5V)(nC) | 8 |
Qg (10V)(nC) | 17 |
VGS(th) max (V) | 2.20 |
Ciss (pF) | 1000 |
Coss (pF) | 290 |
Crss (pF) | 50 |
Qgd (nC) | 4.10 |
tD(on) (ns) | 6.50 |
tD(off) (ns) | 19 |
Trr (ns) | 11 |
Qrr (nC) | 19 |
ESD Diode | No |
Tj max (°C) | 150 |
Qualification | Industrial |
Documentation
| Title | Type | Date | File |
|---|---|---|---|
| AONS36306 Datasheet | Datasheets | 2021-03-11 | |
| AONS36306 Marking | Markings | 2020-05-13 | |
| AONS36306 Reliability Report | Reliability Reports | 2021-05-20 | |
| DFN5x6_8L_EP1_P | Package | 2023-12-19 | |
| DFN5x6_8L_EP1_P Tape & Reel | Tape & Reel | 2024-03-05 |
Package Details
| Package Name | Dimensions | Package Specifications | Packaging Method |
|---|---|---|---|
| DFN5x6_8L_EP1_P | 5.0x6.0x0.95 | Tape and Reel |
